24-Port Multi-Gigabit (2.5G) Ethernet Ultra60 PoE++ Smart Switch with 4 SFP+ Ports
24-Port Multi-Gigabit (2.5G) Ethernet Ultra60 PoE++ Smart Switch with 4 SFP+ Ports
MS324TXUP
1 / 9
Ports
- 24 Ports
Port Types
- 24 x 1G/2.5G 1000 Base-T RJ-45 Copper Ports
- 4 x 10G SFP+ Uplink
- 24 x Ultra60 PoE++ (60W/port) Ports
PoE Budget
- 720 Watts
Details
MS324TXUP
Ports
- 24 Ports
Port Types
- 24 x 1G/2.5G 1000 Base-T RJ-45 Copper Ports
- 4 x 10G SFP+ Uplink
- 24 x Ultra60 PoE++ (60W/port) Ports
PoE Budget
- 720 Watts
Details
Total Network Solution helps you get the most out of your network
Easily deploy, manage, and monitor NETGEAR Insight managed routers, switches, and access points all from a single pane-of-glass.
Built on your feedback. Designed for the way you work.
NETGEAR Insight 10.0—a smarter, simpler way to deploy, monitor, and manage your network.
Technical Specifications
| NETGEAR MS324TXUP with Insight Cloud Management | |
| DC power cord (varies by region) | |
| Rackmount kit | |
| Installation guide | |
Width : | 440mm |
Depth : | 310mm |
Height : | 43.2mm |
Weight : | 9.78lb (4.435kg) |
Multi-gigabit copper ports : | 24 (1G/2.5G) |
SFP+ ports : | 4 |
Number of PoE++ (802.3bt) ports : | 24 |
Total PoE Power budget : | 720 Watts |
Uninterrupted PoE : | Yes |
Max MAC entries : | 32K |
Buffer size : | 2 MB |
VLAN (Number Supported) : | 256 |
VLAN routing : | Yes |
Dynamic VLAN assignment : | Yes |
MLD Snooping : | Yes |
Static route : | Yes (32) |
Host ARP table : | 512 ARP |
EEE : | Yes |
DoS Prevention : | Yes |
Internal/External PSU : | Internal |
Max power (worst case, all ports used, line-rate traffic) : | 765W |
Fans : | 3 |
Acoustic Noise Level @25C : | 38.0 dBA |
Operating Temperature : | 0° to 50° C (32° to 122°F) |
MTBF : | 1,017,939 hrs (116.12 yrs) |
NETGEAR Insight Remote Cloud Management | NETGEAR Insight is the easy-to-use solution for delivering centralized remote management of networks across multiple locations for small business owners, IT managers, MSPs and VARs all from a single pane-of-glass on any device. |
| This product is backed by NETGEAR limited lifetime hardware warranty. |
| Click here for coverage, availability and terms and conditions. |
| NETGEAR Support offers a customizable support experience based on your operational needs: |
|
|
|
|
| Support coverage in one, three, or five year contracts |
