  • 5 x Gigabit Ethernet ports with 4 x PoE+ ports
  • Plug-and-play with fundamental network management features
  • QoS and VLAN management
  • Fanless and silent
  • Desktop or wall-mount
 GS105EP GS105EP-100EUS GS105EP-100EUS

Easy Smart PoE+ Switch (GS105EP) armor

5-Port Gigabit Ethernet Easy Smart PoE+ Switch (63W) armor

Easy Smart PoE+ Switch (GS105EP)

5-Port Gigabit Ethernet Easy Smart PoE+ Switch (63W) armor

  • 5 x Gigabit Ethernet ports with 4 x PoE+ ports
  • Plug-and-play with fundamental network management features
  • QoS and VLAN management
  • Fanless and silent
  • Desktop or wall-mount

5-Port Gigabit Easy Smart | PoE + | GS105EP

5-Port Gigabit Easy Smart | PoE + | GS105EPP

8-port Gigabit Easy Smart | PoE+ | GS108EP

16-port Gigabit Easy Smart | PoE+ | GS116EP

Join Waitlist

Notify me when this item comes back in stock

Please enter a valid e-mail address.

You are already on the list. We’ll notify you shortly.

Successfully registered.

Features

EASY POE CONTROLS
Manage PoE prioritization, PoE power limit per port, PoE scheduling and more for advanced control over all PoE-powered devices
GIGABIT ETHERNET
5 ports provide gigabit Ethernet connectivity to your devices
VLANS
Port-based and 802.1Q-based network separation into smaller groups for more secure and efficient use of network resources
FANLESS DESIGN
Silent operation makes this switch perfect for noise-sensitive environments
VERSATILE MOUNTING OPTIONS
Place your switch on your desktop or mount it to your wall with the hardware provided in the box. Silent operation makes this switch perfect for noise-sensitive environments
ENERGY EFFICIENT
Energy Efficient Ethernet (IEEE 802.3az) standard, which reduces energy consumption when there is light traffic on an active port or when there is no link or no activity detected
Product Datasheet

Technical Specifications

GS105EP
GS105EP
  • Dimensions (W x D x H) : 158 x 101 x 27 mm (6.22 x 4.00 x 1.06 in)
  • Weight : 0.39kg (0.86 lb)
  • Speed : 1G
  • Number of Ports : 5
  • Number of PoE+ Ports : 4
  • PoE Power per Port : Up to 30
  • PoE Budget : Up to 63W
  • Energy Efficient Ethernet Support (IEEE 802.3az) : Yes
  • Jumbo Frame Support : 9,216 bytes
  • MAC Table Size : 2K
  • Packet buffer size : 1.5 MB
  • IEEE 802.1p QoS : Yes
  • Max Power Consumption : 74.7W
  • Operating Temperature : 0-40°C (32°F - 104°F)
  • MTBF (hours) : 1,164,104 hours (132 years)
  • FCC Class : Class B

    • Warranty: This product is backed by a NETGEAR limited lifetime hardware warranty (depending on model and region).
    • Click here for coverage, availability and terms and conditions.
    • Support: ProSUPPORT 24x7 Advanced Technical Support via phone for 90 days (Remote diagnostics performed by our technical experts for prompt resolution of technical issues). ProSUPPORT coverage can be extended by purchasing one, three, or five-year contracts.
    • ProSUPPORT Lifetime 24x7 Advanced Technical Support via chat.
