  • 190W PoE budget across 24 Gigabit PoE+ ports
  • Dedicated SFP fiber uplink ports
  • Advanced L2 smart switching features
  • Easy-to-use web browser-based management GUI
  • Advanced per-port PoE controls
  • Quiet desktop or rackmount placement
  • Energy Efficient Ethernet (IEEE 802.3az) to maximize power savings
  • 3-Year Hardware Warranty
GS324TPv2 GS324TP-200EUS GS324TP-200EUS

Smart Managed Essentials Switch (GS324TPv2) armor

24-Port Gigabit Ethernet PoE+ Smart Managed Essentials Switch with 2 Dedicated SFP Ports (190W) armor

Smart Managed Essentials Switch (GS324TPv2)

24-Port Gigabit Ethernet PoE+ Smart Managed Essentials Switch with 2 Dedicated SFP Ports (190W) armor

Join Waitlist

Order now and we’ll ship as soon as it’s back in stock.

Get It By: Ships By:

Free Shipping & Returns

Join Waitlist

Notify me when this item comes back in stock

Please enter a valid e-mail address.

You are already on the list. We’ll notify you shortly.

Successfully registered.

  • 190W PoE budget across 24 Gigabit PoE+ ports
  • Dedicated SFP fiber uplink ports
  • Advanced L2 smart switching features
  • Easy-to-use web browser-based management GUI
  • Advanced per-port PoE controls
  • Quiet desktop or rackmount placement
  • Energy Efficient Ethernet (IEEE 802.3az) to maximize power savings
  • 3-Year Hardware Warranty

Features

HIGH-DENSITY CONNECTIVITY

Provides 24 Gigabit Ethernet PoE+ ports for connecting numerous devices, plus 2 dedicated SFP ports for high-speed fiber uplinks to your core network

ROBUST POE+ POWER

Delivers a 190W total PoE budget to power a dense deployment of devices like VoIP phones, IP surveillance cameras, and wireless access points

ADVANCED SWITCHING CAPABILITIES

Features L2 management, including VLANs, QoS, LACP, ACL and STP for optimized network performance and security.

INTUITIVE WEB MANAGEMENT

Configure and manage your network with a straightforward, user-friendly web browser-based GUI that simplifies administration.

BUILT FOR RELIABILITY

Includes a 3-year hardware warranty, ensuring dependable performance for growing business networks.

Technical Specifications

gs324tpv2_techspec_desktop gs324tpv2_techspec_mobile

Product specifications

  • NETGEAR 24-Port Gigabit Ethernet PoE+ Smart Managed Essentials Switch
  • Power cord varies by region
  • Rack-mount kit and rubber feet
  • Width
    440mm
  • Depth
    257mm
  • Height
    43mm
  • Weight
    3.53kg (7.78lb)
  • 10/100Mbps ports
    N/A
  • Gigabit ports
    24
  • SFP ports
    2
  • Number of PoE ports
    24
  • PoE+ (802.3at)
    24 (30W per port)
  • Total PoE Power budget (Watts)
    190W
  • Max MAC entries
    8K
  • Buffer size
    1.5MB
  • VLAN (Number Supported)
    64
  • VLAN routing
    Yes
  • Dynamic VLAN assignment
    Yes
  • Host ARP table
    512
  • EEE
    Yes
  • DoS Prevention
    Yes
  • Internal/External
    Internal 100-240VAC, 50-60Hz, 4A
  • Max consumption (Watts)
    208W
  • FAN
    2
  • Acoustic Noise Level @25C (dBA)
    26.1
  • Operating Temperature
    0° to 50° C
  • MTBF
    1,784,610 hours (203.7 years)
  • NETGEAR Web GUI
    Configure your network effortlessly with the user friendly NETGEAR web GUI, no IT expert required.
