NETGEAR Award-winning OrbiTM technology delivers high-performance whole home WiFi.Delivers high-performance WiFi for your family's streaming, gaming and surfing needs.This two pack mesh WiFi system includes one Orbi 4GX router and one WiFi satellite to provide reliable coverage up to 280m2 LBK1220

Orbi 4GX Router with Satellite (LBK1220) armor

Orbi 4GX Router with Satellite Telstraarmor

Award-winning OrbiTM technology delivers high-performance whole home WiFi.Delivers high-performance WiFi for your family's streaming, gaming and surfing needs.This two pack mesh WiFi system includes one Orbi 4GX router and one WiFi satellite to provide reliable coverage up to 280m2

Orbi 4GX Router with Satellite (LBK1220)

Orbi 4GX Router with Satellite Telstraarmor

Award-winning OrbiTM technology delivers high-performance whole home WiFi.Delivers high-performance WiFi for your family's streaming, gaming and surfing needs.This two pack mesh WiFi system includes one Orbi 4GX router and one WiFi satellite to provide reliable coverage up to 280m2

Technical Specifications

  • Orbi 4GX Router (LBR1020) : Dimensions: 131 x 131 x 68mm (5.16 x 5.16 x 2.7in)
  • Weight: 491g (1.08lb)
  • Orbi Satellite (RBS10) : Dimensions: 104 x 104 x 68mm (4.1 x 4.1 x 2.7in)
  • Weight: 245g (0.54lb)
  • WiFi Coverage : 280m2
  • Technology Bands : LTE Cat 18
  • - 4G band (LTE-FDD): B1,3,5,7,8,20,28
  • - 4G band (LTE-TDD): B38,40,41
  • - 3G band: B1,3,5,8
  • WiFi : Orbi 4GX Router & Orbi Satellite (866 + 400Mbps)
  • • AC1200 Dual-band WiFi
  • - Radio 1: IEEE® 802.11b/g/n 2.4GHz–256QAM support
  • - Radio 2: IEEE® 802.11a/n/ac 5GHz–256QAM support
  • Ports : Orbi 4GX Router
  • - One (1) 10/100/1000Mbps Gigabit Ethernet WAN/LAN port
  • - One (1) 10/100/1000Mbps Gigabit Ethernet LAN port
  • Memory : Orbi 4GX Router
  • - 128MB Flash and 512MB RAM
  • Antenna : Wi-Fi Antenna
  • - Two (2) high performance internal antennas each
  • LTE Antenna
  • - Four (4) high performance internal antennas on router only
  • - Two (2) TS9 external antenna ports on router only
  • Processor : Processor – Router & Satellite
  • - Powerful Quad-Core 710MHz processor each
  • Security : Comprehensive anti-virus & data theft protection for your PC, Mac® and mobile devices with NETGEAR Armor™
  • Standards-based WiFi Security (802.11i, 128-bit AES encryption with PSK)
  • Guest WiFi Network is easy to setup separate & secure Internet access for guests
  • One (1) Orbi 4GX Router (LBR1020)
  • One (1) Orbi Satellite (RBS10)
  • One (1) 2m Ethernet cable
  • One (1) 12V/2.5A power adapter (LBR1020)
  • One (1) 12V/1A power adapter (RBS10)
  • One (1) 12V/1A power adapter (RBS10)
