24-Port Gigabit Ethernet High-Power PoE+ Unmanaged Switch with 16-Ports PoE++ (480W)
GS524UP
24-Port Gigabit Ethernet High-Power PoE+ Unmanaged Switch with 16-Ports PoE++ (480W)
1 / 8
24-Port Gigabit Ethernet High-Power PoE+ Unmanaged Switch with 16-Ports PoE++ (480W)
Ports
- 24 Ports
Port Types
- 24 x 10/100/1000 Mbps ports (auto uplink), 8 x 802.3at PoE+ ports, 16 x 802.3bt PoE++ type 3 ports
PoE Budget
- 480W
Details
GS524UP
Ports
- 24 Ports
Port Types
- 24 x 10/100/1000 Mbps ports (auto uplink), 8 x 802.3at PoE+ ports, 16 x 802.3bt PoE++ type 3 ports
PoE Budget
- 480W
Details
Features
ETHERNET PORT CONFIGURATION:
24 Gigabit ports
PLUG-AND-PLAY:
Simple set up with no software to install or configuration needed and zero maintenance
FULL PERFORMANCE:
Non-blocking switching architecture for maximum throughput at wire speed
POWER-OVER-ETHERNET:
16 Ultra60 PoE++, and 8 PoE+ ports with 480W total power budget to power wireless AP, 4K IP Cameras, IP Phones and much more
POWER AUTO-BALANCE AND ALLOCATION:
NETGEAR's unique PoE technology automatically balances the PoE power, delivering exactly what each device needs
SILENT OPERATION:
The fanless design means zero added noise wherever its located, making it ideal for your home or business environment
ENERGY EFFICIENT:
Designed to optimize power usage lowering its cost to operate
RUGGED METAL CASING:
Durable desktop case for longevity
VERSATILE MOUNTING OPTIONS:
Supports desktop or rackmount placement, and includes all mounting hardware in the box
STANDARDS-BASED DESIGN:
Ensure interoperability with any standards-based PDs
Technical Specifications
Dimensions | 330 x 207 x 43 mm (12.99 in. x 8.15 in. x 1.7 in.) | |
Weight | 3.10kg (6.83 lb) |
Speed: | Gigabit | |
Number of Ports: | 24 | |
Number of PoE Ports: | 8 PoE+ ports | |
PoE budget: | 480W | |
Energy Efficient Ethernet Support (IEEE 802.3az): | Yes | |
Jumbo Frame Support: | 9,216 bytes | |
MAC Table Size: | 8K | |
Packet buffer size: | 192 KB | |
IEEE 802.1p QoS: | Yes | |
Max Power Consumption: | 456.8W / 14.9W | |
Fans: | 2 | |
Operating Temperature: | 0° to 40°C (32° to 104°F) | |
MTBF (hours): | 809,853.3 hrs | |
FCC Class: | Class A |
Warranty : | This product is backed by NETGEAR limited lifetime hardware warranty. |
| | Click here for coverage, availability and terms and conditions. |
Support : | NETGEAR Support offers a customizable support experience based on your operational needs: |
| |
|
| |
|
Support coverage in one, three, or five year contracts |
