Wireless AirBridge (WBC502)
Insight Instant Wireless AirBridge
Extend your network by a mile. Wirelessly Bridge networks or provide outdoor WiFi coverage
Abonnement d'un an à NETGEAR Insight
Wireless AirBridge (WBC502)
Insight Instant Wireless AirBridge
Extend your network by a mile. Wirelessly Bridge networks or provide outdoor WiFi coverage
Fonctionnalités
High Performance WiFi
5GHz AC 2x2 with 500mbs at 500ft
Long Distance Outdoors
Usable connections for up to 9000ft (3km)Rated for Outdoors
IP55 enclosure rated to resist harsh weather (water and dust resistant, long sun exposure, snow, hail, frost…)Bridge the Gaps
High-gain directioinal 14 dBi AntennaFlexible Mounting Options
Included mounting accessories, for easy outdoor installation on walls, polesUnobtrusive design
Easily blend into many deployment enviromentsPower Supply
Use exclusively with the power supply provided in the boxLine-of-site Outdoor Point-to-point
Outdoor long-distance wireless bridge for over a mile (2 units required)
Local or Remote Insight Management 1-Year Insight Management Included
Point-to-multipoint
Designate one AirBridge as host and connect to multiple AirBridge as SatellitesPower Outdoor Security
Connect AirBridge to existing wireless networks and ethernet hardwire IP camerasOutdoor Access Point
Local Management mode onlyExperience Safety
Connect Outdoor IP surveillance camera for home and business security
Outdoor WiFi expansion
Take WiFi outdoors to where no wires have gone before such as golf-courses etcMultiple buildings
Expand connectivity faster than perminant infastuture allowsCampgrounds
Cover large outdoors areas mulitple configurationsSchools
Improve campus connectivity to remote buildingsCaractéristiques techniques


- Dimensions : 186mm (L) x 100mm (W) x 29mm (H) (7.54” x 4.49” x 1.88”)
- Weight : 504g (1.11lbs)
- Model Description : Insight Instant Wireless AirBridge (WBC502)
- Frequency Band : 5GHz
- Operating Temperature : -20°C~60°C (-4°F~140°F)
- Humidity : 0%~90% typical
- Mounting : Pole Mounting Assemble a mounting bracket to fix this Access Point on a pole
- Wall Mounting Mount this Access Point on a flat wall
- Networking Interface : Two (2) 10/100/1000 BASE-T RJ-45 Ethernet Ports
- Multi-User MIMO : Yes
- Throughput : Delivers 500Mbps at 500ft (166m) distance at line-of-sight for long distance applications Maximium up to 9000ft (3,000M) with reduced bandwith
- Deployment options : Outdoor Point-to-Point Wireless Bridge: extend a network up to 9000ft (3km)
- Outdoor WiFi Client Bridge: provide a WiFi connection to an outdoor device that is not WiFi-capable
- Outdoor WiFi Access Point: outdoor long-range WiFi connectivity
- LEDs : Display system and wireless transmission status
- Outdoor Protection : Main unit is IP55 Protected against dust and water. Power supply must remain protected indoors.


- Wireless : Wifi Technology: Primary 5GHz 802.11 ac 2x2 MIMO. Compatible with 802.11 ac/a/n mode. (Secondary 2.4 Ghz radio is only for management).
- Multiplexing : OFDM with TDMA
- Maximum Signal Output : 23dBM (Output dependent on regulatory domain with)
