D2200D ADSL Gateway

802.11n ADSL gateway offers high-end quality and reliability in an economical solution

The NETGEAR D2200D is a single WAN 802.11n ADSL gateway platform that offers operators a highly cost-effective solution with the NETGEAR quality, reliability, ease-of-use and best-in-class performance they expect. The D2200D allows end-users to experience fast N300 speeds, consistent and reliable connections and an easy-to-manage network from one-touch set-up, with Push ‘N’ Connect (WPS), to simplified troubleshooting with NETGEAR genie® application.

Model: D2200D
Contact Us

Key Benefits

  • NETGEAR quality, reliability and ease-of-use
  • Small form factor
  • Enables DSL deployment in cost sensitive environment
  • Fast WiFi N300 speeds for a reliable video and streaming experience
  • Secure WiFi access
  • Private and public WiFi access
  • TR-069 for remote management for faster troubleshooting and support
  • Future-proof for continued network
  • Simple one-button set-up with Push ‘N’ Connect (WPS)

Key Features

  • ADSL/ADSL2+
  • 2x2 11n WiFi
  • 4FE LAN ports
  • WPA/WPA2 and WPS
  • TR-069
  • IPV6 dual-stack
  • NETGEAR genie graphic user interface
Product Number
D2200D
Product Thumbnail
System Requirements
  • ADSL 2+ Broadband Internet Service
  • 2.4 GHz Wi-Fi client or Ethernet Cable
  • Microsoft® Windows 8, Microsoft Windows 7, Vista, XP, or other operating systems running a TCP/IP network
  • Microsoft Internet Explorer 6.0 or higher
Physical Interfaces
  • WAN Port: ADSL2+
  • Wireless: 802.11n (2.4 GHz)
  • 4 x 10/100 Ethernet switch; 1 mapped to optional Ethernet WAN
Security
  • Wi-Fi Protected Access® (WPA-WPA2-PSK)
  • Firewall: Stateful packet inspection
  • Denial-of-service (DoS) attack prevention
  • NAT traversal (VPN pass-through) for PPTP, L2TP VPNs
  • Static IP address assignment, internal DHCP server on LAN, DHCP client on WAN
Power
  • 12VDC at 0.5A
  • On/Off power button
Environmental Specifications
  • Operating temperature: 0º to 40º C
  • Operating humidity: 90% maximum relative humidity, non-condensing
Network Management
  • Active WAN Uplink Selection and status monitor
  • Advanced Settings: Wireless, Port
Forwarding, Port Triggering
  • Firmware upgrade via LAN (HTTP)
  • Scheduling tasks by time of day
  • Setup: LAN, DNS, Static Routes
  • Statistics
  • TR-069
  • UPnP
Statistics (by LAN/WAN Port)
  • Link Status
  • Transmit / receive traffic in packets
  • Collisions
  • Up time
  • Poll Interval between updates
  • WAN Monitoring
LEDs
  • Power
  • Ethernet LAN 1
  • Ethernet LAN 2
  • Ethernet LAN 3
  • Ethernet LAN 4
  • Wireless
  • DSL Link
  • Internet
  • WPS button
Data Link Layer
  • Bridging
  • PPPoE (Client)
  • IPoE
  • VLAN
Network/Internet Layer
  • IGMP v2, v3
  • IPv4 (IPv6 support possible in future release)
  • PPTP, L2TP pass-through
  • NAT/PAT
  • Static routing
WiFi
  • N300 dual band concurrent
  • Disable SSID broadcast
  • Disable Wi-Fi radio
  • MAC address access control
  • Multiple SSIDs
  • WEP 64/128 bit
  • WMM-QoS
  • WPA, WPA-PSK
  • WPA2, WPA2-PSK
  • WPS with pin & push button
Compliances
  • FCC
  • UL
Model Summary
  • ADSL2+ router with 802.11n Wi-Fi. 4 x 10/100 LAN FE
Package Content
  • Router
  • RJ-11 phone cable
  • RJ-45 Ethernet cable
  • Power supply
  • GPL License
