Price:

In Stock

Product Type: Access Point(s)
* Maximum of 4 products
Features:
  • Easy setup and centralized, remote management with NETGEAR Insight
  • High speed, density and coverage - 2x2 Dual Band 802.11ac Wave 2
  • Maximize performance - Multi-gigabit WiFi throughput (up to 1.2 Gbps) with Gigabit Ethernet port
  • 802.3af Power over Ethernet - Simplify deployment and flexibility
  • Business Class Security - WPA, WPA2, and rogue AP detection.Operating Temperature:32° to 104°F (0° to 40°C)
  • Optimize WiFi coverage automatically with the best coverage and the least interference with Instant WiFi
tcm:11-80936,tcm:11-81053,tcm:11-81037,tcm:11-80973,tcm:11-80976,

COMPARE PRODUCTS

image description

INSIGHT MANAGED SMART CLOUD WIRELESS ACCESS POINT (WAC510)

Frequency Band

  • 2.4GHz and 5GHz

Multi-User MIMO

  • Yes

Maximum Theoretical Throughput

  • 400 Mbps (2.4Ghz)
  • 867 Mbps (5GHz)

Power over Ethernet / PoE

  • PoE IEEE 802.3af

Routing Function

  • Yes
plus
image description

INSIGHT INSTANT MESH MULTI-MODE ACCESS POINT (WAC564)

Frequency Band

  • 2.4GHz and 5GHz

Multi-User MIMO

  • Yes

Maximum Theoretical Throughput

  • 400 Mbps (2.4Ghz)
  • 867 Mbps (Low 5GHz)
  • 1733 Mbps (High 5GHz)

Power over Ethernet / PoE

  • n/a

Routing Function

  • No
plus
image description

INSIGHT MANAGED SMART CLOUD TRI-BAND 4X4 WIRELESS ACCESS POINT (WAC540)

Frequency Band

  • 2.4GHz and 5GHz

Multi-User MIMO

  • Yes

Maximum Theoretical Throughput

  • 400 Mbps (2.4Ghz)
  • 867 Mbps (Low 5GHz)
  • 1733 Mbps (High 5GHz)
  • 3Gbps AC3000

Power over Ethernet / PoE

  • IEEE 802.3at (PoE+)

Routing Function

  • No
plus
image description

INSIGHT MANAGED SMART CLOUD TRI-BAND 4X4 WIRELESS ACCESS POINT (WAC540B03)

Frequency Band

  • 2.4GHz and 5GHz

Multi-User MIMO

  • Yes

Maximum Theoretical Throughput

  • 400 Mbps (2.4Ghz)
  • 867 Mbps (Low 5GHz)
  • 1733 Mbps (High 5GHz)

Power over Ethernet / PoE

  • IEEE 802.3at (PoE+)

Routing Function

  • No
plus
image description

INSIGHT MANAGED SMART CLOUD WIRELESS ACCESS POINT (WAC505)

Frequency Band

  • 2.4GHz and 5GHz

Multi-User MIMO

  • Yes

Maximum Theoretical Throughput

  • 400 Mbps (2.4Ghz)
  • 867 Mbps (Low 5GHz)
  • Up to 1.2 Gbps

Power over Ethernet / PoE

  • IEE 802.3af or 802.3at

Routing Function

  • No
plus

PRODUCT SPECIAL FEATURES

image description
image description
Remote monitoring and management with NETGEAR Insight
  • Instant discovery & set-up
  • Local and Cloud monitoring and management through the Insight app or Cloud Portal
  • Remote access and multi-device configuration
  • No additional Cloud controller, appliance, network manager, or PC/server is necessary
  • QR code intial configuaration for instant installation
image description
image description
INSTANT WIFI

Optimize your WiFi. Instant WiFi analyzes the environment and negotiates the best power and channels automatically. Get the best WiFi coverage and minimal interference.

Configuration is simple.

  • Click "Optimize Now" in the NETGEAR Insight app or Cloud Portal
  • Manual configuration available for expert users
  • Automatic configuration is available across all 3 radios (2.4GHz, low 5GHz, High 5GHz)
image description
image description

INSTANT CAPTIVE PORTAL

NETGEAR Instant Captive Portal gives the business owner the ability to set up a professional captive portal within minutes, with the features and capabilities similar to that of a major franchise.

WATCH NOW

Available to Purchase on Insight

TECH SPECS

  • Model Description
    • The NETGEAR® Insight Managed Wireless Access Point WAC510 delivers high performance WiFi and high client density for enterprises requiring ubiquitous and reliable wireless for all business applications
    • Facebook WiFi Check-in
  • Frequency Band
    • 2.4GHz and 5GHz
  • Multi-User MIMO
    • Yes
  • Maximum Theoretical Throughput
    • 400 Mbps (2.4Ghz)
    • 867 Mbps (5GHz)
  • SNMP
    • v1, v2c
  • Deployment options
    • Standalone
    • NETGEAR Insight management solution
  • PoE
    • PoE IEEE 802.3af
  • Instant Mesh
    • No
  • Security
    • WPA2 Enterprise supported
    • Wireless access control to identify authorized wireless network devices
    • MAC address authentication
  • MAC ACL
    • Yes
  • Routing Function
    • Yes
  • 802.11AC Wave
    • Wave 2
  • Simultaneous Bridge/Client Association
    • Yes
  • VLAN Support
    • Yes
  • Bandwidth Management
    • Yes
  • Power
    • Power adapter (not included): 12V DC, 2.5A; plug is localized to country of sale
  • LEDs
    • Five (5) LED: Power, Link/ACT, LAN, 2.4GHz, 5GHz
  • Mounting
    • Easy ceiling mounting/wall mounting
  • Bonjour Gateway
    • No
  • Link Layer Discovery Protocol
    • Yes
  • Default Reset
    • Yes
  • Product Ordering Information
    • WAC510-10000S, WAC510-100NAS
    • WAC510PA-100NAS
    • WAC510B03-10000S, WAC510-100NAS
+

Netgear Warranty

This product is backed by a NETGEAR 5-year Hardware Warranty.
ProSUPPORT 24x7 Advanced Technical Support via phone for 90 days (Remote diagnostics performed by our technical experts for prompt resolution of technical issues). ProSUPPORT coverage can be extended by purchasing one, three, or five year contracts.
ProSUPPORT 24x7 Advanced Technical Support via chat for 90 days.
